Schneider Electric Tesys d contactor lc1d12p7 3p 12a ac-3 5.5kw@400v 1no+1nc
Lc1D12P7 is a 3-pole TeSys d contactor from Schneider electric for motor applications up to 5.5kW@400V. It includes a 230V 50/60Hz ac coil and 1no+1nc built-in auxiliary contacts, it can be used in sa… Les mer …
Kjøp på nett
Sist oppdatert 26. juni, 10:03. Lenkene er annonse-/samarbeidslenker – Prisguider.no kan motta provisjon ved kjøp. Det påvirker ikke prisen din eller rekkefølgen (laveste totalpris vises først).
Produktinfo
Lc1D12P7 is a 3-pole TeSys d contactor from Schneider electric for motor applications up to 5.5kW@400V. It includes a 230V 50/60Hz ac coil and 1no+1nc built-in auxiliary contacts, it can be used in safety applications thanks to its certified nc mirror contact.
Compact, din-rail mounting, it procures high reliability and durability. Available worldwide, it is multi-standards certified (iec, ul, csa, ccc, eac, Marine) and Green Premium compliant (RoHs/Reach). Compact product, 45mm wide, for din-rail and panel mounting.
Clear separation between power and control circuits, easy front access to coil and auxiliary contacts connections. Equipped with a 230V ac coil that can be supplied at 50Hz or 60Hz. Provides 2 built-in auxiliary contacts 1no + 1nc, nc is a certified mirror contact suitable to be included in the control of safety systems.
High electrical durability, guaranteed for 2 million cycles at 12A ac-3 440V, for demanding motor switching applications. Robust design with high making and breaking capacities up to 20 In.
